1550nmSOA半导体放大器
1550nm Semiconductor Optical Amplifier (SOA)
PDF资料下载
Parameter | Unit | Specification | ||
Min | Typ. | Max | ||
Part No. | - | LQ-1550SOA-P-A-CM-PW-PF-C | ||
Operating wavelength | nm | 1530 | 1550 | 1570 |
Optical input power | dBm | -30 | 0 | -5 |
Optical output power | dBm | 3 | 12 | |
Noise figure(0dBm input) | dB | 7 | 9 | |
PDG | dB | 0.5 | ||
Pump remnant to output | dBm | -30 | ||
Pump remnant to input | dBm | -30 | ||
Return loss(SOA off) | dB | 40 | ||
Power supply | V(AC) | 100 | 220 | 240 |
Fiber type | - | SM-28 fiber | ||
Power consumption | W | 8 | 16 | 25 |
Operating temperature | ℃ | -5 | 55 | |
Storage Temperature | ℃ | -20 | 70 | |
User interface | LCD shows internal operating parameter， LED shows operation status and alarm | |||
Network interface | RS232，LANorUSB | |||
Dimensions (L×W×H) | mm | 90×70×19(Module)， 483×385×44(1U 19" rack) or 320×220×90(Benchtop)， etc | ||
Order Information：LQ-1550SOA-P-A-CM-PW-PF-C
P:Package，B-Benchtop，M-Module，U-1U 19 rack
A:Application，example :B=Power amplifier，L=In-line amplifier，P=Pre-amplifier
CM:Control mode，ACC=Automatic current control，APC=Automatic power control
AGC=Automatic Gain Control
PW: Output power in dBm， example:7-7dBm ，10-10dBm，15-15dBm
PF:Pigtail fiber，0=250um，1=900um，2=2mm，3=3mm
C:Connector，FU=FC/UPC，FA=FA/APC，SA=SC/APC
