1480nm DFB激光光源
PDF资料下载
量青光电1480nmDFB光源。中心波长1480+/-1nm，线宽≤10MHz，功率10mW
Parameters | Unit | |
Part No. | - | LQ-DFB-1480-P-PW-SP |
Central wavelength | nm | 1480±1 |
-3dB spectral width | MHz | ≤10 |
Output power | mW | 10 |
Output power short-term stability | dB | ≤±0.005dB/15 min |
Output power long-term stability | dB | ≤±0.01dB/8 hour |
Operating mode | - | CW |
Power Attenuator | - | 0~10 |
Attenuator Precision | mW | 0.1 |
Fiber pigtail | - | Single mode SMF-28 |
Output connector | - | FC/UPC or FC/APC， etc |
Operating temperature | ℃ | 0 ~ 40 |
Storage temperature | ℃ | -20 ~ 70 |
Power supply | - | +5V DC; >500mA; △V＜1%(Module); AC 110/220V±10%， 50Hz， 20W(Desk-top) |
Dimensions (L×W×H) | mm | 90×70×19 Module; 320×220×90 Benchtop |
Remark: Stability is tested at room temperature 25±2℃ after pre-heating 30 minutes.
1. Test condition: fixed temperature， CW.
2. Test condition: temperature variation ±2℃， CW.
Order Information：LQ-DFB-1180-P-PW-SP-FA
P:Package，B-Benchtop，M-Module
PW: Output power in mW， example:1-1mW ，10-10mW
SP: Feedback protection， 0-None，1-Yes
