1350nmSLD宽带光源
中心波长1350+/-10nm，带宽超过40nm，功率＞1mW，可按需提供激光器或者光源
Parameters： | Unit | |
Part No. | - | LQ-SLED-1350-P-PW-SP |
Central wavelength | nm | 1350±10 |
-3dBSpectral width | nm | ≥40，etc |
Output power | mW | 1，5，10，20，30，35，etc |
Ripple | dB | ≤0.2 |
Output power short-term stability | dB | ≤±0.01dB/15 min |
Output power long-term stability | dB | ≤±0.03dB/8 hour |
Operating mode | - | CW |
Fiber pigtail | - | Single mode SMF-28 |
Output connector | - | FC/UPC or FC/APC， etc |
Operating temperature | ℃ | 0 ~ 40 |
Storage temperature | ℃ | -20 ~ 70 |
Power supply | - | AC 110/220V±10%， 50Hz， 20W |
Dimensions (L×W×H) | mm | 90×70×19 Module; 320×220×90 Benchtop |
Remark: Stability is tested at room temperature 25±2℃ after pre-heating 30 minutes.
1. Test condition: fixed temperature， CW.
2. Test condition: temperature variation ±2℃， CW.
Order Information：LQ-SLED-1350-P-PW-SP
P:Package，B-Benchtop，M-ModulePW: Output power in mW， example:1-1mW，5-5mW，10-10mW，35-35mW，etc
SP: Feedback protection， 0-None，1-Yes
