980nmSLD宽带光源
PDF资料下载
980nmSLED宽带光源，台式，中心波长980+/-20nm，带宽超过30nm，功率＞2mW。
其他波长激光器或者光源，我们咨询。提供750-1700nm全覆盖波长。
Parameters | Unit | |
Part No. | LQ-SLED-980-P-PW-SP | |
Central wavelength | nm | 980±20 |
-3dB spectral width | nm | ≥30 |
Output power | mW | ≥2 |
Spectral density stability | dB | ≤±0.05dB/15 min |
Output power short-term stability | dB | ≤±0.01dB/15 min |
Output power long-term stability | dB | ≤±0.03dB/8 hour |
Operating mode | - | CW(extemal modulation is optional) |
Fiber pigtail | - | Single mode SMF-28 |
Output connector | - | FC/UPC or FC/APC， etc |
Operating temperature | ℃ | 0 ~ 40 |
Storage temperature | ℃ | -20 ~ 70 |
Power supply | - | AC 110/220V±10%， 50Hz， 20W |
Dimensions (L×W×H) | mm | 90×70×19 Module; 320×220×90 Benchtop |
Remark: Stability is tested at room temperature 25±2℃ after pre-heating 30 minutes.
2. Test condition: temperature variation ±2℃， CW.Order Information：LQ-SLED-980-P-PW-SP
P:Package，B-Benchtop，M-ModulePW: Output power in mW， example:2-2mWSP: Feedback protection， 0-None，1-Yes
