800-1100nmSLD超宽带光源
PDF资料下载
Description: |
超宽带光源由多个宽带光源组合而成，带宽在750～1750nm范围内可自由选择组合， *宽工作范围可达300nm。功率10mW |
Applications: | Features: |
工作带宽**可达300nm 光谱密度**可达-20dBm/nm 光谱密度稳定度高 | 光纤传感系统 光纤无源器件性能测试 光纤器件自动化测试系统 |
Parameters | Unit | |
Part No. | - | LQ-SLED-800~1100-P-PW-SP |
Central wavelength | nm | 800-1100 |
-3dB Spectral width | nm | 300 |
Output power | mW | >10 |
Power spectral density | dBm/nm | Normally ≥-30 (max to -20) |
Ripple | dB | ≤0.2 |
Output power short-term stability | dB | ≤±0.02dB/15 min |
Output power long-term stability | dB | ≤±0.04dB/8 hour |
Operating mode | - | CW |
Fiber pigtail | - | Single mode hi1060 |
Output connector | - | FC/PC， FC/UPC or FC/APC， etc |
Operating temperature | ℃ | 0 ~ 40 |
Storage temperature | ℃ | -20 ~ 70 |
Power supply | - | AC 110/220V±10%， 50Hz， 20W |
Dimensions (L×W×H) | mm | 320×220×90 Benchtop |
Remark: Stability is tested at room temperature 25±2℃ after pre-heating 30 minutes.
1. Test condition: fixed temperature， CW.
2. Test condition: temperature variation ±2℃， CW.
Order Information：LQ-SLED-800~1100-P-PW-SP
P:Package，B-Benchtop PW: Output power in mW， example:20-20dBm/nm，30-30dBm/nm，40-40dBm/nmSP: Feedback protection， 0-None，1-Yes
